Parallel mini butterfly female-female valves PN 16
Material
Chromed brass
Max. output pressure
16 bar
Temperature
-10°C to 90°C
Plus de références
Reference
Net weight (kg)
Female thread
FSI 10
FSI 13
FSI 17
FSI 21
Dimensions
Reference
A (mm)
B (mm)
C (mm)
D (mm)
E (mm)
FSI 10
42
21
FSI 13
42
21
FSI 17
42
21
FSI 21
47
25
| Reference | Net weight (kg) | Female thread | 3D |
|---|---|---|---|
| FSI 10 | 0,095 Kg | G1/8 | |
| FSI 13 | 0,086 Kg | G1/4 | |
| FSI 17 | 0,074 Kg | G3/8 | |
| FSI 21 | 0,113 Kg | G1/2 |
Dimensions
| Reference | A mm | B mm |
|---|---|---|
| FSI 10 | 42 | 21 |
| FSI 13 | 42 | 21 |
| FSI 17 | 42 | 21 |
| FSI 21 | 47 | 25 |
